Product Detail
| Standard |
|
 Frequency Band |
 2.400GHz ~ 2.484GHz |
| Data Rate |
802.11g: 54, 48, 36, 24, 18, 12, 9 & 6Mbps 802.11b: 11, 5.5, 2 and 1 Mbps with auto-rate fall back |
| Number of operation channel |
2.412~2.462GHz (Canada, FCC) / 11 Channels 2.412~2.484GHz (Japan, TELEC) / 14 Channels 2.412~2.472GHz (Euro, ETSI) / 13 Channels |
| Sensitivity |
-73dBm @ 802.11g -85dBm @ 802.11b |
| Security |
64/128bit WEP WPA (TKIP with IEEE 802.1x) WPA2 (AES with IEEE 802.1x) |
| Access Protocol |
CSMA/CA |
| Driver support |
Windows® 2000, XP 32/64, Vista 32/64 |
| RF Output Power (Typical) |
802.11g: up to 18 ± 1 dB 802.11b: up to 19 ± 1 dBm |
| Interface |
USB 2.0 |
| Antenna |
One detachable 5dbi antenna (SMAconnector) |
| Operation Voltage |
5V |
| Dimension (mm) |
99 (L) x 60 (W) x 16 (H) mm |
| Operation Temperature |
0°C ~ 60°C |
| Storage Temperature |
-20°C ~ 70°C |
| Storage Temperature |
20~70℃ ambient temperature |
| Storage Humidity |
10% ~ 90% (Non-condensing) |
