Photocopy Canon IR2630i

33.999.000 LAK
Instock , Prin - Scan - copy A3 , 100 sheet Duplex Document Feeder • 30 pages per minute in B&W • 2 x 550-sheet paper trays • Copy, print and scan • Network Ready • Colour Scanning • Wi-Fi • Duplex and electronic collation
Quantity
-
+
Product Detail
Machine Type A3 Monochrome Laser Multifunctional
Core Functions Print, Copy, Scan, Send and Optional Fax
Control Panel Standard: 7 inch TFT LCD WVGA Colour Touch panel
Memory Standard: 2.0GB RAM
Paper Supply Capacity (A4, 80gsm) Standard: 1,200 sheets
Maximum: 2,300 sheets (with Cassette Feeding Unit-AN1)
Paper Output Capacity (A4, 80 gsm) Standard: 250 sheets
Maximum: 545 sheets (with Inner Finisher-J1)
Supported Media Sizes Upper Cassette 1:
Standard size: A4, A4R, A5R, B4, B5, B5R
Custom size: Min. 139.7 x 182.0 mm up to 297.0 x 390.0 mm

Lower Cassette 2:
Standard size: A3, A4, A4R, A5R, B4, B5, B5R
Custom size: Min. 139.7 x 182.0 mm up to 297.0 x 431.8 mm

Multi-purpose tray:
Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, Envelopes [No. 10(COM 10), Monarch, ISO-C5, DL]
Custom Size/Free Size: Min. 98.0 x 148.0 to 297.0 x 431.8 mm
Supported Media Weights Paper Cassettes (1/2): 60 to 128 gsm
Multi-purpose tray: 52 to 220 gsm (Thin: vertical grain paper feed only: 52 to 59 gsm)
Duplex: 60 to105 gsm
Warm-up Time
(Quick start mode:ON)
12 seconds or less*1
From Sleep Mode: 10 seconds or less
4 Seconds or less*2
Dimensions (W x D x H) 586 x 713 x 912 mm (with DADF-AZ1)*3
Installation Space (W x D) 1363 x 1273 mm (with DADF-AZ1)*4
Weight Approx. 66.8 kg without toner

Print
Print Speed (ppm) 30 ppm (A4), 15 ppm (A3)
Print Resolution (dpi) 1,200 x 1,200
Page Description Languages Standard: UFR II, PCL 6
Optional: Genuine Adobe PostScript 3
Fonts PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T*5 (Japanese, Korean, Simplified and Traditional Chinese) , Barcode fonts*6
PS fonts: 136 Roman
Operating System UFRII: Windows® 7/8.1/10/Server 2008 /Server 2008 R2/Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.9 or later)
PCL: Windows® 7/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016/Server 2019
PS: Windows® 7/8.1/10/Server 2008/Server 2008 R2/ Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.9 or later)
PPD: Windows® 7/8.1/10, MAC OS X (10.9 or later)

Copy
Copy Speed (ppm) 30 ppm (A4), 15 ppm (A3)

First-Copy-Out Time (A4) Approx. 5.9 seconds or less

Copy resolution (dpi) Reading: 600 x 600
Printing: Up to 1,200 x 1,200
Multiple Copies Up to 9,999 copies

Copy Density Automatic or Manual (9 Levels)

Magnification 25% - 400% (1% Increments)

Preset Reductions 25%, 50%, 61%, 70%, 81%, 86%
Preset Enlargements 115%, 122%, 141%, 200%, 400%

Scan
Selectable Type Optional Document Feeder(DADF-AZ1) or Platen Cover Type Z

Document Feeder Paper Capacity (80 gsm) DADF-AZ1: 50 Sheets
Acceptable Originals and Weights DADF-AZ1:
1-sided scanning: 38 to 128 gsm (BW/CL)
2-sided scanning: 38 to 128 gsm (BW/CL)*8
Supported Media Sizes Platen: Max. scanning size: 297.0 x 431.8 mm
Document Feeder media size:
DADF-AZ1:
A3, A4, A4R, A5, A5R, B5, B5R, B4R
Custom size: 128.0 x 148.0 mm to 297.0 x 431.8 mm
Scan Speed (ipm: BW/CL; A4) DADF-AZ1:
1-sided Scanning:35/25 (BW/CL; 300 dpi), 25 (BW; 600 dpi)
2-sided Scanning:12/8 (BW/CL; 300 dpi), 8 (BW; 600 dpi)
Scan Resolution (dpi) Copy: 600 x 600
Send: (Push) up to 600 x 600, (Pull) up to 600 x 600
Fax: up to 600 x 600
Pull Scan Specifications Colour Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows® 7/8.1/10
Windows® Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016
Scan Method Send functionality available on all models
Scan to USB Memory Key: Available on all models
Scan to Mobile Devices and cloud-based services: A range of solutions is available to provide scanning to mobile devices or cloud-based services depending on your requirements. Please contact your sales representative for further information.
TWAIN/WIA Pull scanning available on all models

Send (optoinal)
Destination E-mail/Internet FAX (SMTP), SMB, FTP, WebDAV, Super G3 FAX (Optional)
Address Book LDAP (2,000)/Local (1,600)/Speed dial (200)
Send Resolution (dpi) Push: 600 x 600
Pull: 600 x 600, 400 x 400, 300 x 300, 200 x 200, 150 x 150, 75 x 75
Communication Protocol File: FTP (TCP/IP), SMB (TCP/IP), WebDAV
E-mail/I-Fax: SMTP (send), POP3 (receive)
File Format Standard: TIFF (MMR), JPEG*9, PDF (Compact, PDF A/1-b, Encrypted), XPS (Compact), PDF/XPS (Device Signature)
Optional: PDF (Trace & Smooth), PDF/XPS (User Signature, Searchable), Office Open XML (PowerPoint, Word)

Fax (Optoinal)
Optional / Standard Optional on all models
Maximum Number of Connection Lines 1
Modem Speed Super G3: 33.6 kbps
G3: 14.4 kbps
Compression Method MH, MR, MMR, JBIG
Resolution (dpi) 400 x 400 (Ultrafine), 200 x 400 (Superfine), 200 x 200 (Fine/Photo), 200 x 100 (Normal)
Sending / Recording Size A3, A4, A4R, A5*10, A5R*10, B4, B5*11, B5R*10
FAX / Memory Up to 30,000 pages
Speed Dials Max. 200
Group Dials / Destinations Max. 199 dials
Sequential Broadcast Max. 256 addresses
Memory Backup Yes

Store
Memory Media Standard: USB Memory

Security
Authentication Standard: uniFLOW Online Express, User Authentication, Department ID Authentication, Access Management System, Picture Login
Optional: My Print Anywhere secure print (Requires uniFLOW)
Network Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP, S/MIME
Document Standard: Secure Print, Encrypted PDF, Encrypted Secure Print, Device signature
Optional: User signature

Environmental
Operating Environment Temperature: 10 to 30 ºC (50 to 86 ºF)
Humidity: 20 to 80 % RH (Relative Humidity)
Power Source 220-240 V , 50/60 Hz , 5.2 Amp
Power Consumption Maximum: Approx. 1500W
Standby: Approx. 20W
Sleep mode: Approx. 0.6 W

Consumables
Toner Cartridge/s NPG-84 Toner Black
Toner (Estimated Yield @ 6% Coverage) Black: 30,000 impressions (A4)

Paper Supply Options
CASSETTE FEEDING UNIT-AN1 Paper Capacity: 550 sheets x 2 (80 gsm)
Paper Type: Thin, Plain, Thick, Colour, Recycled, Pre-punched
Paper Size: A3, A4, A4R, A5R, B4, B5, B5R, Custom size: 139.7 x 182.0 to 297.0 x 431.8 mm
Paper Weight: 60 to 128 gsm
Power Source: From the Main Unit
Dimensions (W x D x H): 565 x 650 x 248 mm (attached to the main unit)
Weight: Approx. 23.5 kg
ENVELOPE FEEDER ATTACHMENT-D1 Attaches to the 2nd paper drawer for easy envelope feeding. Holds up to 50 envelopes.

Output options
INNER 2WAY TRAY-L1 Allows the separation of copies, prints and faxes. Adds a second internal output tray to give a combined output capacity of 350 sheets (upper tray 100 sheets/lower tray 250 sheets).
INNER FINISHER-J1 (Internal) Number of Trays: 2
Upper Tray Capacity*12: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R: 45 sheets
Lower Tray Capacity*12: A4, A5, A5R, B5: 500 sheets, A3, A4R, B4, B5R 250 sheets, A6R: 30 sheets
Paper Weight: 52 to 220 gsm
Staple Position: Corner, Double

Staple Capacity: Corner and Double Stapling:
A4/B5: 50 sheets (52 to 90 gsm)
A3/A4R/B4: 30 sheets (52 to 90 gsm)

Eco Staple:
A3/A4/B4/B5:
5 sheets (52 to 64 gsm)
4 sheets (65 to 81.4 gsm)
3 sheets (81.5 to 105 gsm)

Staple On Demand:
40 sheets (80 gsm)
Dimensions (W x D x H): 604 x 535 x 205 mm (when the extension tray is extended)
Weight: Approx. 7.3 kg

Hardware Accessories
Card Readers COPY CARD READER-F1 - Magnetic physical card access system. (Integrates with Department ID, not for use with uniFLOW)
IC Card Reader Box-C2
COPY CARD READER ATTACHMENT-H3 - Attachment kit for Copy Card Reader-F1 only.
Others UTILITY TRAY-B1 - Additional tray to hold an external USB keyboard
Document Tray-J1
Platen Cover Type Z
Platen Cover Type Y
DADF-AZ1
DADF-BA1

System and Controller options
Print Accessories PCL INTERNATIONAL FONT SET-A1 - Adds PCL support for Andalé Mono WT J/K/S/T (Japanese/Korean/Simplified Chinese/Traditional Chinese).
PS PRINTER KIT-BT1- Provides networked printing support for Adobe PostScript 3 printing.
Send Options Universal Send Digital User Signature Kit-C1
Universal Send Advanced Feature Set-H1
Barcode Printing BARCODE PRINTING KIT-D1 - Provides the ability to print 1D and 2D barcodes on output using jet caps technology.
System Accessories COPY CONTROL INTERFACE KIT-D1: Allows connection (CCVI I/F) between 3rd party copy control terminal and Canon’s iR-ADV range for cost recovery use.
FAX Accessories SUPER G3 FAX BOARD-AV2
REMOTE FAX KIT-A1 - Enables the device to send and receive fax from another device connected with a fax board

Other Options
Accessibility Accessories ADF ACCESS HANDLE-A1 - Attaches to the document feeder, making access easier for seated users.
Staple Cartridge STAPLE-P1 - For stapling (2 x 5,000 pcs)

1.Time from device power-on, until copy ready (not print reservation).
2.Time from device power-on to when key operations can be performed on the touch panel display.
3.With the multi purpose tray extended.
4.With Cassette open + 100 mm gap around the main body.
5.Requires optional PCL International Font Set-A1.
6.Requires optional Barcode Printing Kit-D1.
7.Only 1-sheet feeding is supported in 38-42 gsm. (Feeding is guaranteed but geometric distortion correction is not guaranteed.)
8.Only 1-sheet feeding is supported in 38-52 and 105-128 gsm. (Feeding is guaranteed but geometric distortion correction is not guaranteed.)
9.Single page only.
10.Sent as A4.
11.Sent as B4.
12.With 81.4 gsm paper.
